Single-phase Asynchronous motor RM80-Cb/2
(Equipment / Material)
Model Number: RM80-Cb/2
Condition: New
Made in: Italy
Location or Storage Country: Italy
Service Engineering Support: Yes
Warranty: No
Price: Call for price
Description:
Single-phase asynchronous squirrel-cage motor from the R series, 2-pole (3000 rpm). The motor has an output of 2.6 kW, nominal torque of 8.9 Nm. The frame is made of extruded aluminium. Cooling method – IC411 (self-cooled). Protection class – IP54. The motor features sealed bearings. Various mounting configurations (B3, B5, B14) and terminal box positions (right or left) are available.
Overview:
| Parameter | Value |
|---|---|
| Power | 2.6 kW |
| Speed | 2800 rpm |
| Number of poles | 2 |
| Voltage | 230 V |
| Frequency | 50 Hz |
| Current | 17 A |
| Efficiency | 75% |
| Power factor | 0.98 |
| Nominal torque | 8.9 Nm |
| Capacitor value | 13.5 µF |
| Protection class | IP54 |
| Cooling method | IC411 (self-cooled) |
| Frame material | Aluminium (extruded) |
| Frame size | R80 |
| Mounting | B3, B5, B14 |
| Ambient temperature | Standard |
Documentation:
CME Srl (Electric Motor Construction)
Locations: Via del Lavoro, 14, 40050 Argelato (BO), Italy
Main Products/Services: Three-phase and single-phase asynchronous motors, dual-polarity motors, inverter-duty motors, "E" series motors, "R" series motors.
Registration: Via del Lavoro, 14, 40050 Argelato (BO), Italy
