Add product
Product / Equipment

Control Unit Type A with Integrated Solenoid Valve

(Equipment / Material)
Control Unit Type A with Integrated Solenoid Valve
Model Number: 8.300.01-1
Condition: New
Made in: Germany
Location or Storage Country: Germany
Service Engineering Support: Yes
Warranty: No
Price: Call for price
Description:
The Control Unit Type A is a safety control device with an integrated solenoid valve, designed for use in hazardous area applications. The unit is available with a hand-held terminal approved for Zone 1 potentially explosive atmospheres. The housing is constructed from highly-resistant, impact-resistant polycarbonate and includes a 12-meter cable. The control unit is TÜV-proofed, confirming its compliance with safety standards for use in explosive environments. The unit is classified under ANA-systems (exhaust air monitoring systems) and is designed to integrate with safety storage cabinets and other hazardous substance management equipment. The control unit can be paired with various cut-off flap sets including DN 50 and DN 80 configurations. The device enables centralized control of safety functions in hazardous material storage areas.
Overview:
Article number8.300.01-1
Product rangeSafety equipment
HW-categoryANA-systems
Outer width (approx.)280 mm
Outer depth (approx.)280 mm
Outer height (approx.)280 mm
Weight (approx.)8 kg
Housing materialHighly-resistant, impact-resistant polycarbonate
Cable length12 m
ApprovalHand-held terminal approved for Zone 1 potentially explosive atmospheres
CertificationTÜV-proofed
Documentation:
Attached file #1
#control unit #solenoid valve #explosive atmosphere #ANA-system #safety
Company Profile

Düperthal Security Technology GMBH & CO. KG

Markets: Research laboratories, pharmaceutical companies, chemical industry, educational institutions, and industrial facilities handling hazardous substances. Customer testimonials include Smart lab solutions, Labforward, FLUICS GmbH, and Futurehub.nrw.
Locations: 63791, Germany, Karlstein, Frankenstrasse 3
Main Products/Services: Safety storage cabinets (Type 90 for flammable liquids, lithium-ion batteries, non-flammable media, combined storage); Safety equipment (control units, exhaust air monitoring systems, ventilation units, filter units); Pedal operated dipping tanks (cleaning tanks); Intelligent storage management system (DÜPERTHAL connect); Accessories (earthing cables, transport trolleys, collection trays, document storage boxes, universal absorbers).
Year Established: 1953
